EU 51.2v 300ah 16kwh lifepo4 battery pack wall movable 200a bms wifi bluetooth
Reviews
- Stock: In Stock
- Brand: DOCAN ENERGY
- Model: ZZ48300WM
- Weight: 125.00kg
- Dimensions: 54.00cm x 25.00cm x 75.00cm
This offer ends in:
ZZ48300WM-16kWh
A high-capacity LiFePO4 energy storage battery designed for residential and commercial energy storage applications, combining a 51.2V 300Ah battery system with smart BMS monitoring, communication and flexible installation.
Smart energy storage in a compact design
Built around 16 matched 300Ah LiFePO4 cells with intelligent battery management and flexible communication options.
16S1P battery configuration with matched lithium iron phosphate cells.
Integrated voltage, current, short-circuit and temperature monitoring and protection.
Monitor battery information through smart connectivity and mobile APP.
Communication support for PC monitoring and compatible inverter systems.
RS485 parallel communication supports up to 16 battery strings.
Long-cycle LiFePO4 battery chemistry designed for long-term energy storage.
Compact enclosure designed for wall-mounted or mobile installation configurations.
Supports up to 200A maximum continuous discharge current.
Technical specifications
Electrical, mechanical and environmental parameters based on the ZZ48300WM battery specification.
822 × 242 × 535 mm
A compact 51.2V 300Ah battery enclosure designed to provide high energy capacity while minimizing installation space.
Intelligent battery protection
The integrated BMS continuously monitors battery operating conditions and provides multiple layers of protection and system management.
Bluetooth & WiFi monitoring
Access key battery information through smart monitoring tools. The BMS provides battery data including voltage, current, temperature, SOC, SOH and operating status.
Designed for popular inverter systems
RS485 and CAN communication support enables integration with a wide range of commonly used energy storage inverter platforms. Cable pin definitions may vary between inverter models.
Dual fan cooling for stable operation
Two top-mounted cooling fans promote airflow and efficient heat dissipation during charging and high-load operation. This active cooling design helps maintain a more stable internal operating environment for the battery system.
Up to 16 battery packs
The BMS RS485 parallel communication interface supports a maximum of 16 battery strings simultaneously. Individual pack addresses are configured using DIP switches.
Long-term after-sales support
DOCAN ENERGY provides long-term warranty and after-sales support for our energy storage battery systems. For warranty terms, installation requirements and service conditions, please refer to our official warranty policy.
Ready for safe transportation
The battery and supplied accessories are prepared for transport with protective packaging.
From cell matching to final testing
Battery production includes cell matching, assembly, BMS integration, electrical connection, testing and final packaging.
Need ZZ48300WM-16kWh batteries?
Contact DOCAN ENERGY for stock availability, wholesale pricing, inverter compatibility and delivery information.
